5 Programming Worksheets
27
[404] Panel ID Code (Enter 6 Hexadecimal Digits)
[405] Answering Machine Double-Call Timer
Default 060 I_______I_______I_______I Valid entries are 000-255 seconds
[406] Number of Rings To Answer On
Default 000 I_______I_______I_______I Valid entries are 000-255 rings
[501]-[514] PGM Output Attributes
Program only the following attributes for the PGM options listed. All others are ignored.
|_______|_______|_______|_______|_______|_______|
Default = 140400
Main board
[501] PGM 1
|___|___|___|___|___|___|___|___|
[502] PGM 2
|___|___|___|___|___|___|___|___|
PC5208
[503] PGM 3
|___|___|___|___|___|___|___|___|
[504] PGM 4
|___|___|___|___|___|___|___|___|
[505] PGM 5
|___|___|___|___|___|___|___|___|
[506] PGM 6
|___|___|___|___|___|___|___|___|
[507] PGM 7
|___|___|___|___|___|___|___|___|
[508] PGM 8
|___|___|___|___|___|___|___|___|
[509] PGM 9
|___|___|___|___|___|___|___|___|
[510] PGM 10
|___|___|___|___|___|___|___|___|
PC5204
[511] PGM 11
|___|___|___|___|___|___|___|___|
[512] PGM 12
|___|___|___|___|___|___|___|___|
[513] PGM 13
|___|___|___|___|___|___|___|___|
[514] PGM 14
|___|___|___|___|___|___|___|___|
12 3 4 5 6 78
PGM
Option
=ON
OFF
Not Used
–
Not Used
–
True Output
Inverted
Follows Timer
ON/OFF
Code Req.
No Code
Not Used
No
Not Used
No
Not Used
No
Attribute:
00 Null PGM (Not Used)
01 Burglary and Fire Siren Output
02 Not Used
03 Sensor Reset (*72)
04 2-Wire Smoke Support (PGM 2 Only)
05 Armed Status
06 Ready To Arm
07 Keypad Buzzer Follow
08 Courtesy Pulse
11 System Tamper
12 TLM and Alarm
13 Kiss-off Output
14 Ground Start Pulse
15 Remote Operation
16 Not Used
17 Away Armed Status
18 Stay Armed Status
19 Command Output #1 [*][7][1]
20 Command Output #2 [*][7][2]
21 Command Output #3 [*][7][3]
22 Command Output #4 [*][7][4]
23 For Future Use
24 For Future Use
25 Delayed Burglary and Fire Bell
Output
26 Battery Test Output
To Next Page
