DSC PowerSeries PC1404 Installation Guide

1 Introduction
1
1 Introduction
This manual provides installation and programming information
for the PC1404 four-zone panel security system.
1.1 Compatibility Requirements
The PC1404 product is the central component of the four-zone
security system. Interaction with associated system devices is
hardwired, which follows DSC keybus standards. Communica-
tions with the central station may be achieved by a hardwired
phone line. DLS may also be remotely connected to the panel via
phone line or locally connected via the PC-Link header. Shown
below are the supported and unsupported modules for the
PC1404.
1.2 Product Specifications
Control and Indicating Equipment Specifications
Features
• Supports zone doubling — supervised and distinguishable
• NC/Single/Double EOL support
• Supports up to 4 keypads
• 1 Partition support
• 128 events
• Communications: on-board PSTN
• 4 phone numbers
• 2-wire smoke detector support
• 4-wire smoke detector support
• Auto-arming
7DEOH6XSSRUWHG0RGXOHV
Module Current Draw, mA Software Versions
PC1404RKZ/PC1404RKZWH
Keypads
145/150 1.0
PK5500/PK5501/PK5508/PK5516
Keypads
125 1.0, 1.1, 1.2, 1.3
LCD5511 Fixed Message LCD
Keypad
85 1.0
LED5511Z 8-Zone LED Keypad
100 1.0
PC1555RKZ 8-Zone LED Keypad
85 2.0
PTK5507 Touchscreen keypad
200 (standby)
300 (activated)
400 (Extra Power mode)
1.0
PC5200 Power Supply
20 2.0
PC5204 Power Supply with 4
PGMs
20 2.0
PC5208 Low Current PGM Module
20 1.0
PC5601 LED Status Module
30 1.0
TL300 T-Link TL300 IP Alarm
Communicator
360 1.2-1.5
GS3105/3125-K & BA Wireless
Alarm Communicator
250 (excluding outputs) 3.0
7DEOH8QVXSSRUWHG0RGXOHV
7DEOH&RPSDWLEOH6PRNH'HWHFWRU0RGHOV
Module 4-Wire Smoke Detectors 2-Wire Smoke Detectors
PC5100 2-wire interface PC5964 Large Audio Station FSA-410x FSA-210x
RFK55XX Keypad PC5401 RS232 Module FSA-410xT FSA-210xT
RF5132-433 Wireless Receiver PC5400 Printer + DVACS FSA-410xS FSA-210xS
RF5108-433 Wireless Receiver
Escort 5580 Telephone
Interface
FSA-410xST FSA-210xST
PC5108 Zone Expander
TL260 Series
Communicators
FSA-410xLST FSA-210xLST
PC5320 Zone Expander
GS2060 Series
Wireless Alarm Communicator
FSA-410xR FSA-210xR
PC5950 Audio Module TL250 Communicator FSA-410xRT FSA-210xRT
PC5904 Large Audio Station TL150 Communicator FSA-410xRS FSA-210xRS
PC5921 Audio Station IT100 Integration Module FSA-410xRST FSA-210xRST
PC5961, PC5962 Small Audio
Station
IT120 Integration Module FSA-410xLRST FSA-210xLRST
Note: For model numbers above, x = A (ULC); x = B (UL); x = C
(CE)

DSC PowerSeries PC1404 Specifications

General

Brand	DSC
Model	PowerSeries PC1404
Category	Security System
Language	English
