PC1404
16
5.2 Programming Worksheets
Keypad Partition/Slot and Function Key Programming
[000] Function Key Programming
Note: Keypad enrollment must be done at each keypad requiring programming. Function keys are programmable in each individual
keypad. The keypad being programmed must be used to access Installer Programming, followed by Section [000] and digits 1-5 for
function keys 1 to 5.
Function Key Options:
[001] Zone Definitions
[001] Zone 1–8 Definitions
[0] Slot address For the partition, 0-8; for the slot, 1-8. For example, to enroll a keypad on the main partition and slot
6, enter 16.
[1] Function Key 1 Assignment Valid entries are 00-25
[2] Function Key 2 Assignment Valid entries are 00-25
[3] Function Key 3 Assignment Valid entries are 00-25
[4] Function Key 4 Assignment Valid entries are 00-25
[5] Function Key 5 Assignment Valid entries are 00-25
00 Null Key 09 Future Use 18 Future Use
01 Future Use 10 Future Use 19 [][7][3] Command Output #3
02 Future Use 11 Future Use 20 Night Arm
03 Stay Arm 12 Future Use 21 [][7][4] Command Output #4
04 Away Arm 13 [][7][1] Command Output #1 22 Future Use
05 [][9] No Entry Arm 14 [][7][2] Command Output #2/Sensor Reset 23 Future Use
06 [][4] Chime On / Off 15 Future Use 24 Future Use
07 Future Use 16 [][0] Quick Exit
25 Instant Stay Arm
*
08 [][1] Bypass Mode 17 [][1] Reactivate Stay/Away Zones 26-33 Future Use
*
This function key must not be used in CP-01 listed systems.
Key 1 Key 2 Key 3 Key 4 Key 5
Keypad Defaults
BBB BBB BBB BBB BBB
00 Null Zone (Not Used) 14 24 Hour Heat* 28 Not Used
01 Delay 1* 15 24 Hour Medical* 29 Not Used
02 Delay 2* 16 24 Hour Panic* 30 Not Used
03 Instant* 17 24 Hour Emergency* 31 Day Zone
04 Interior* 18 Not Used 32 Instant Stay/Away*
05 Interior, Stay/Away* 19 24 Hour Water* 33 Not Used
06 Delay, Stay/Away* 20 24 Hour Freeze* 34 Not Used
07 Delayed 24 Hr. Fire 21 24 Hour Latching Tamper 35 24 Hour Bell
08 Standard 24 Hr. Fire 22 Momentary Keyswitch Arm* 36 24 Hr. Non-Latching Tamper
09 24 Hour Supervisory 23 Maintained Keyswitch Arm * 37 Night Zone*
10 24 Hour Supervisory Buzzer* 24 Not Used 41 24-Hour CO Detection
11 24 Hour Burglary* 25 Interior Delay*
12 Not Used 26 24-hour Non-Alarm (Local Alarm)
13 24 Hour Gas* 27 Not Used
*For burglary applications only
Zone Default Zone Default
01 01
I_____I_____I
05 (ZD or keypad zone only) 04
I_____I_____I
02 03
I_____I_____I
06 (ZD or keypad zone only) 04
I_____I_____I
03 03
I_____I_____I
07 (ZD or keypad zone only) 04
I_____I_____I
04 03
I_____I_____I
08 (ZD or keypad zone only) 04
I_____I_____I
Note: If zone doubling is enabled, keypad zones will not work.
Note: If zone doubling is enabled, fire zones cannot be used with zone terminals 1 to 8. Two-
wire smoke detectors can still be used.
