PC1404
20
[030] Zone Loop Response Options
[101]-[108] Zone Attributes
[101] Zone 1 Attributes
[102] Zone 2 Attributes
[103] Zone 3 Attributes
[104] Zone 4 Attributes
[105] Zone 5 Attributes
[106] Zone 6 Attributes
[107] Zone 7 Attributes
[108] Zone 8 Attributes
Zone Attribute Defaults
7
Trouble Beeps are Silent
Trouble Beeps Sound Every 10 seconds
8
Keyswitch Arms In Away Mode Only
Keyswitch Arms In Stay or Away Modes
Opt Def. ON OFF
1
Zone 1 is Fast Loop Response
Zone 1 is Normal Loop Response
2
Zone 2 is Fast Loop Response
Zone 2 is Normal Loop Response
3
Zone 3 is Fast Loop Response
Zone 3 is Normal Loop Response
4
Zone 4 is Fast Loop Response
Zone 4 is Normal Loop Response
Attribute: 1 2 3 4 5 6 7 8
=ON
Audible Steady Chime Bypass Force Swing Tx. Delay Not used
Zone Type: OFF Silent Pulsed No No No No No
00 Null Zone
01 Delay 1
02 Delay 2
03 Instant
04 Interior
05 Interior Stay/Away
06 Delay Stay/Away
07 Delay 24-hr. Fire (Hardwired)
08 Stand 24-hr. Fire (Hardwired)
09 24-hr. Supervisory (Hardwired)
10 24-hr. Supervisory Buzzer
11 24-hr. Burglary
12 Not Used
13 24-hr. Gas
14 24-hr. Heat
15 24-hr. Medical
16 24-hr. Panic
17 24-hr. Emergency
18 Not Used
19 24-hr. Water
20 24-hr. Freeze
21 24-hr. Latching Tamper
22 Momentary Keyswitch Arm
23 Maintained Keyswitch (Hardwired)
24 Not Used
25 Interior Delay
26 24-hr. Non-Alarm
27–30 Not Used
31 Day Zone
32 Instant Stay/Away
33-34 Not Used
35 24-hr. Bell/Buzzer Zone Type
36 24-hr. Non-Latching Tamper
37 Night Zone
41 24-hr. Carbon Monoxide Detection
* For UL installations, do not change attribute 5 (Force Arming) from the default setting. For CP-01 installations: Option 6 (Swinger) is defaulted ON for zone
definitions 09-11, 13-17, 19, 20. Option 7 (Tx Delay) is defaulted ON for zone definitions 01-06, 09-11, 13-17, 19, 20, 25, 32, 36, 37.
