DSC PowerSeries PC1404 Installation Guide

PC1404
28
Zone Follower PGM requires 2 programming sections for attributes: the normal PGM attribute Sections [501-514] and Sections [551-
564] for zone assignment.
[551]-[564] PGM Zone Assignment
27 Police Code

28 For Future Use
29 Zone Follower

30 Status Alarm Memory

Notes:
A change of default setting will NOT affect the output.
A change of default setting will affect the output.
Attribute:
123 4 56 7 8
ON
OFF
Service Req.
Event
AC Fail TLM Fault FTC Enabled Device Fault Device
Tamper
Device Low
Battery
Loss of
Clock
Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled
09 System Trouble
   
Attribute:
123 4 56 7 8
ON
OFF
Burglary
Event
Fire
Event
Panic Event Medical
Event
Supervisory
Event
Priority
Event
Duress Event Output
Follows
Timer
Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled
10 System Event
  
Note:
If a System Event PGM is programmed to follow the Command Output Timer, attribute 8 must be enabled.
Location PGM 29 Zone Follower
Option On Option Off
Option 1 For Future Use
Option 2 For Future Use
Option 3 True Output Inverted
Option 4 For Future Use
Option 5 For Future Use
Option 6 For Future Use
Option 7 For Future Use
Option 8 AND Logic Or Logic
Section Number Output Number Zone Follower Zone
Main Board 1 2 3 4 5 6 7 8
[551] PGM 1
[552] PGM 2
PC5208
[553] PGM 3
[554] PGM 4
[555] PGM 5
[556] PGM 6
[557] PGM 7
[558] PGM 8
[559] PGM 9
[560] PGM 10
12 3 4 5 6 78
PGM
Option
 =ON
OFF
Not Used
–
Not Used
–
True Output
Inverted
Follows Timer
ON/OFF
Code Req.
No Code
Not Used
No
Not Used
No
Not Used
No
