Programming PK5500 Keypads
If you have an PK5500 keypad, additional programming is required for proper operation. All LCD programming is done per keypad. If
more than one LCD keypad is present on the system, labels programmed at one keypad can be broadcast to all other LCD keypads. The
following is a description of the available programming options and their accompanying programming sections:
How to Enter LCD Programming
Programming LCD keypads is similar to programming the rest of the system. Follow the programming procedure as outlined in Section
3 of the Installation Manual.
1. Enter keypad programming by pressing [*][8][Installer Code].
2. Press the [*] key.
3. Enter the three-digit section number to be programmed (see the following for section numbers).
Programmable Labels
Zone labels and other LCD display identifiers can be customized to make operation of the system easier for the end user. The following
procedure should be used for creating all LCD labels:
1. Enter Installer Programming. Enter the three-digit section number for the label to be programmed.
2. Use the arrow keys (<>) to move the underline bar underneath the letter to be changed.
3. Press the number key [1] to [9] corresponding to the letter you require. The first time you press the number the first letter will
appear. Pressing the number key again will display the next letter.
Refer to the following chart:
[1] - A, B, C, 1 [6] - P, Q, R, 6
[2] - D, E, F, 2 [7] - S, T, U, 7
[3] - G, H, I, 3 [8] - V, W, X, 8
[4] - J, K, L, 4 [9] - Y, Z, 9,0
[5] - M, N, O, 5 [0] - Space
4. When the required letter or number is displayed use the arrow keys (<>) to scroll to the next letter.
5. When you are finished programming the Zone Label, press the [*] key, scroll to “Save,” then press [*].
6. Continue from Step 2 until all Labels are programmed.
[000] Keypad Function Key Programming
The five function keys on the alarm panel can be reprogrammed as described below. See How to Program Function Keys for default.
Note: Each keypad must be individually programmed.
[1]
Function Key 1 Assignment (Valid entries are 00-25)
[2]
Function Key 2 Assignment (Valid entries are 00-25)
[3]
Function Key 3 Assignment (Valid entries are 00-25)
[4]
Function Key 4 Assignment (Valid entries are 00-25)
[5]
Function Key 5 Assignment (Valid entries are 00-25)
Entry Description Option Description
[00] Null Key: Program non functioning keys with this option [15] Not Used
[01]-[02] Not Used [16] Quick Exit: See [16] [*][0] Quick Exit
[03] Stay Arm: See [03] Stay Arm [17] Reactivate Stay/Away Zones: See [17] [*][1] Reactivate
Stay/Away Zones
[04] Away Arm: See [04] Away Arm [18] Not Used
[05] No Entry Arm: See [05] [*][9] No Entry Arming [19] Command Output #3: See [19] [*][7][3] Command Output 3
[06] Chime On/Off: See [06] [*][4] Door Chime On/Off [20] Night Arm
[07] Not Used [21] Command Output #4: See [21] [*][7][4] Command Output 4
[08] Bypass: See [][1] on [08] Zone Bypassing [22]-[24] Not Used
[09]-[12] Not Used [25] Instant Stay Arm: See [25] Instant Stay Arming
[13] Command Output #1: See [13] [*][7][1] Command Output [26]-[33] Not Used
[14] Command Output #2: See [14] [*][7][2] Smoke Detector
Reset/Sensor Reset
