5.3 Programming Descriptions

09 System Trouble. This PGM output switches to ground when any of the selected Troubles are detected. The output de-acti-
vates when all of the selected Troubles are restored. The PGM attributes for this output are unique for this PGM type and the
standard attributes do not apply. The PGM attributes for this output are as follows:
1 Service Required
*
5 Fire Trouble/Zone Fault
2 A.C. Failure 6 Zone Tamper
3 Telephone Line Fault 7 Zone Low Battery
4 Communications (Failure to Communicate) 8 Loss of Clock
Note: * = Battery, Bell circuit, General System Trouble, General System Tamper, General System Supervisory Troubles,
PC5204 Low Battery and PC5204 AC Fail
10 System Event Output. This PGM output switches to ground when any of the selected system events (alarms) occur on the sys-
tem. In the armed state, the output will deactivate only once the system is disarmed.
If an alarm causes this output to activate in the disarmed state, the output will deactivate if a user enters a valid access code while
the bell is still active. If BTO has occurred, the PGM will deactivate if someone arms the system after the bell cut-off has
expired. This output can be used to indicate that an alarm has occurred before entering the premises. The PGM attributes for this
output are unique and the standard attributes do not apply. Program the events that will activate the output by selecting some or
all of the following PGM attributes:
i
Note: This PGM output activates for alarm conditions only. Pre-alerts or delays do NOT activate the output. When this output
follows the output timer, events that have been disabled from activating the output do not restart the timer.
11 System Tamper. This PGM output switches to ground when any Tamper condition occurs on the system and deactivates when all
Tamper conditions on the system are cleared. These tampers include zone tampers (DEOL), 24 Hr Latching or Non-latching Tamper
Zones, module tampers and keypad tampers. This output will also activate for the following events): Bell Circuit Trouble, TLM
Trouble, Keybus Fault, Zone Expander Supervisory, General System Supervisory, and General System Tamper.
12 TLM and Alarm. The output activates when a Telephone Line Trouble (TLM) condition is present followed by an alarm
condition. The output will remain active until an access code is entered to disarm the partition. The output will activate for all
audible and silent alarms except for duress if a TLM trouble is present at the time of the alarm. If an alarm activates this out-
put in the disarmed state, it will deactivate when the system is armed or the telephone line trouble is restored.
13 Kiss-off. This output will activate (switch to ground) for two seconds after the panel receives the kiss-off signal from the cen-
tral station receiver.
14 Ground Start. This PGM output is used for old telephone systems where Tip and Ring need to be shorted together briefly to
get dial tone. The output will activate for two seconds before the panel attempts dialing to obtain a dial tone on Ground Start
telephone equipment. Two 2-second pauses (hex E) must be inserted at the beginning of the telephone number when using
this option.
15 Remote Operation. This output can be activated or deactivated remotely by using DSC's Downloading Software.
16 Not Used
17 Away Armed Status. This output will activate at the beginning of exit delay when the system is armed using away mode.
Some markets, like Europe and France, require that this PGM activate at the end of exit delay which is when the panel is tech-
nically armed.
18 Stay Armed Status. This output will activate when the system is armed with the stay/away zones bypassed.
PGM output types [17] and [18] are designed to follow the status of the stay/away zones. If the system is armed with stay/
away zones bypassed, the stay output should be active. If the system is armed with the stay/away zones active, the AWAY
armed status PGM will turn on. The following indicates how these arming techniques work:
STAY key Stay
[*][9] + Code Stay
AWAY key Away
Keyswitch Arm Depends on delay type zone during exit delay
[*][0] Quick Arm Depends on delay type zone during exit delay
Access Code Arm Depends on delay type zone during exit delay
DLS Arm Away
Auto Arm Away
Stay Armed, then [*][1] Away
PGM Output Options
1 Burglary
2 Fire
3 Panic
4 Medical
5 Supervisory
6 Priority
7 Not Used
8 Latched
Delay, Instant, Interior, Stay/Away and 24-Hour Burg. zones
Key, Fire zone
Key and Panic zone
Auxiliary Key, Medical and Emergency zones
Supervisory, Freezer and Water zones
Gas, Heat, Sprinkler and 24-Hour Latching zones
Output Follows Pulse timer/Output Latching
