Appendix A: Reporting Code Formats
[345]-[346] Bell Circuit Trouble/Rest. Software deactivates the bell output if a short is detected
so no additional current is taken from the battery./Bell out-
put restored.
MA/R E(3)21-000/ YA-99/YH-99
[345]-[346] Fire Trouble/Rest.
2-wire Smoke Trouble/Rest.
Trouble occurs/restore on a fire zone
Trouble occurs/restore on 2-wire smoke detector zone
MA/R E(3)73-000/
R(3)73-000
FT-00/FJ-00
FT/FJ-99
[345]-[346] Auxiliary Power Trouble/
Rest.
Aux voltage supply trouble/restore MA/R E(3)12-000/
R(3)12-000
YP-00/YQ-
00
[346] TLM Restore Telephone line restored MA/R E(3)51-000 LR-01
[345]-[346] Gen. System Trouble/Rest. “Service Required” trouble occurs (view troubles using
[*][2])/trouble restored
MA/R E(3)AA-000 YX-00/YZ-00
[345]-[346] Gen. System Supervisory
Trouble/Rest.
Control panel has detected an alternate communicator
fault/communications restored.
MA/R E(3)3A-000 ET-00/ER-00
[346] Cold Start The PC1404 has restarted after total power loss. MA/R R(3)A5-000 RR-00
[347] Phone 1-4 FTC Restore Control panel has restored communications to central
station on Phone 1, 2, 3 or 4 (after FTC)
MA/R R(3)54-000 YK-00
[347] Event Buffer is 75% Full Event buffer is almost full since last upload MA/R E(6)22-000 JL-00
[347] DLS Lead In Downloading session start MA/R E(4)11-000 RB-00
[347] DLS Lead Out Downloading session complete MA/R E(4)12-000 RS-00
[347] Zone Fault/Rest. One or more zones have faults/restored MA/R
E(3)8A-ZZZ/
R(3)8A-ZZZ/
UT-ZZ/UJ-ZZ
[347] Delinquency Programmed amount of time (days or hours) for
delinquency has expired without zone activity, or without
system being armed
MA/R E(6)54-
000***
CD-00
[347] Installer Lead In Installer’s mode has been entered MA/R E(6)27-000
LB-00
[347] Installer Lead Out Installer’s mode has been exited MA/R E(6)28-000 LS-00
[348] Walk Test End End of test T
R(6)A7-UUU
TE-UU
[348] Walk Test Begin Beginning of test T
E(6)A7-UUU
TS-UU
[348] Periodic Test Periodic system test transmission T E(6)A2-000 RP-00
[348] System Test [*][6] bell/communications test T E(6)A1-000 RX-00
*
**
***
A/R = alarms/restores; T/R = tampers/restores; O/C = openings/closings; MA/R = miscellaneous alarms/restores;
T = test transmissions
UU = user number (user 01-39, 40); ZZ = zone number (01-08).
Use the “Fail to close” event code [(4)54] to report closing or activity delinquency. Ensure the central station is aware that this
code is used.
Table 1: Reporting Codes
6HFWLRQ 5HSRUWLQJ&RGH &RGH6HQW:KHQ
'LDOHU
'LUHFWLRQ
$XWRPDWLF
&RQWDFW,'
&RGHV
6,$$XWR
5HS&RGHV
Table 2: Contact ID Programmed Zone Alarm/Restoral Event Codes
(as per SIA DCS: ‘Contact ID’ 01-1999): Program any of these codes for zone alarms/
restores when using the standard (non-automatic) Contact ID reporting format.
Medical Alarms (1)34 Entry / Exit
(1)AA Medical (1)35 Day / Night
(1)A1 Pendant Transmitter (1)36 Outdoor
(1)A2 Fail to Report In (1)37 Tamper
Fire Alarms (1)38 Near Alarm
(1)1A Fire Alarm General Alarms
(1)11 Smoke (1)4A General Alarm
(1)12 Combustion (1)43 Exp. Module Failure
(1)13 Water Flow (1)44 Sensor Tamper
(1)14 Heat (1)45 Module Tamper
(1)15 Pull Station (1)4A Cross Zone Police Code
(1)16 Duct 24 Hour Non-Burglary
(1)17 Flame (1)5A 24 Hour non-Burg
(1)18 Near Alarm (1)51 Gas Detected
Panic Alarms (1)52 Refrigeration
(1)2A Panic (1)53 Loss of Heat
(1)21 Duress (1)54 Water Leakage
(1)22 Silent (1)55 Foil Break
(1)23 Audible (1)56 Day Trouble
Burglar Alarms (1)57 Low Bottled Gas Level
(1)3A Burglary (1)58 High Temp
(1)31 Perimeter (1)59 Low Temp
(1)32 Interior (1)61 Loss of Air Flow
(1)33 24 Hour
