PowerSeries - PC1616/PC1832/PC1864
20
[310] System Account Number
Program the System Account Number. Only the SIA format supports 6-digit account numbers. If a 4-digit account number is required,
program the last two digits as data [FF]. When using the SIA format, this account number will be used for all reporting events. When using a
different format, this account number will be used for all events that are not partition-specific (for example, low battery, AC trouble, etc.).
For partition-specific events the system will use the programmed Partition Account Number. For all formats other than SIA, program a HEX
[A] for any digit [0] in the account number being used.
[311] to [318] Partition Account Numbers
Program the Partition Account Number for each active partition ([311] for partition 1, [312] for partition 2, etc.). When using the Automatic
SIA format, these account numbers are not used. The system will use the System Account Number for all reporting events. For all formats
other than SIA, program a HEX [A] for any digit [0] in the account number being used.
[320] to [349] Reporting Codes
Program the reporting code for all events to be transmitted. For a description of when each reporting event will be transmitted, refer to
Appendix A – Reporting Codes. The panel also supports Automatic SIA and Automatic Contact ID reporting. Program data [00] to disable
the reporting of an event. If any other data is programmed (Data [01] to [FF]), the panel will automatically generate the correct reporting
event when transmitting to the central station. For all formats excluding Automatic SIA and Automatic Contact ID, the panel will not attempt
to report an event if data [00] or data [FF] is programmed for the reporting code.
[350] Communicator Format
Program the 2-digit number for the desired Communicator Format for the First Phone Number and the Second Phone Number. When dialing
the Third Phone Number, the system will use the Communicator Format programmed for Phone Number 1. Refer to the Programming Work-
sheet for a list of the available Communicator Formats. See Appendix F for details.
[351] to [376] Communicator Call Direction Options
Reporting events are categorized into 5 groups: Alarm/Restore, Opening/Closing, Tamper Alarm/Restore, System Maintenance, and Test
Transmissions. Program which Phone Number the control panel will use to transmit reporting events by turning the option ON in the correct
section. Phone Number 1 and/or Phone Number 2 can be used.
[377] Communicator Variables
Program a 3-digit number for each program entry:
[378] Test Transmission Time
Program the time the system will report a Test Transmission reporting event. Program 4 digits – [HH][MM] using the twenty-four-hour sys-
tem. For a test transmission at 11:00 pm, program data [23][00]). Valid entries are [00][00] to [23][59]. Entering [99][99] will disable the test
transmission.
[379] Periodic DLS Time of Day
Programs the time the system will auto-call DLS. Program 4 digits – [HH][MM] using the twenty-four-hour system. For a DLS auto-call at
11:00 pm, program data [23][00]). Valid entries are [00][00] to [23][59]. Programming [99][99] will select a random time, [FF][FF] will dis-
able it.
Swinger Shutdown (Alarms): Maximum number of alarm/restoral transmissions per zone. Valid entries: [001] to [014]. Program data [000] to
disable shutdown.
Swinger Shutdown (Tamper): Maximum number of tamper alarm/restoral transmissions per zone. Valid entries: [000] to [014]. Program data
[000] to disable shutdown.
Swinger Shutdown (Trouble): Maximum number of trouble alarm/restoral transmissions per trouble condition. Valid entries: [000] to [014].
Program data [000] to disable shutdown.
Communicator (Transmission) Delay: Time, in seconds, the panel will delay reporting an alarm event. Valid entries: [000] to [255].
AC Failure Communication Delay: Time, in minutes, the panel will delay reporting an AC trouble event. Valid entries: [000] to [255].
TLM Trouble Delay: Time, in 3-second intervals, before the system will consider the phone line disconnected. Valid entries: [003] to [255]
(e.g., 3 x10 seconds = 30 seconds).
TLM Restoral follows the same delay.
Test Transmission Cycle (Land Line): Number of days between test transmission reporting events. Valid entries: [001] to [255].
Wireless Zone Low Battery Delay: Number of days the system will delay reporting a wireless low battery to the central station.
Valid entries: [000] to [255]. Program data [000] for no delay.
Delinquency Transmission Delay: Number of hours (Activity Delinquency) or days (Arming Delinquency) the panel will delay before transmit-
ting the event to the central station. Valid entries: [001] to [255].
Communication Cancel Window: Time, in minutes, after an alarm has occurred that the system will report a Communication Cancel reporting
event if the system is disarmed. They keypad will beep rapidly to indicate that the Communication Cancel reporting event has been communi-
cated successfully. Valid entries: [001] to [255]. Entering [000] will disable this window.
