DTS Z8 User Manual

DMX ADDRESS
Z8 LED CONTROLLER can be used in 8 DMX modes: 112 ch, 80 ch, 64 ch, 32 ch,14 ch, 10 ch,
1ch or CUSTOM channels mode.
Full type - 8 bit
If you want to select the next projector, just add “32”
Z1 type - 8 bit
Projector 1 A001
Projector 2 A011 If you want to select the next projector, just add “10”
Projector 3 A021
….. A….
projector 6 A051
Selelcting the DMX address
1) Press the UP-DOWN key until you reach the required DMX address. The numbers on the
display will start flashing (but the new DMX address hasn't yet been set).
2) Press ENTER to confirm your selection. The numbers on the display will stop flashing and the
projector is now controlled by the new DMX address.
TIPS: if you keep pushed the UP or DOWN keys, the channels are calculated more quickly and
you get a faster selection.
If you want to use the Z8 in 32 channels mode, select the “ ” mode from the
DMX MODE menu under MODE SETTINGS and set the following addresses on the mixer:
Projector 1 A001
Projector 2 A033
Projector 3 A065
….. A….
projector 6 A161
If you want to use the Z8 in 10 channels mode, select the “ ” mode from the
DMX MODE menu under MODE SETTINGS and set the following addresses on the mixer:
Z8 LED Controller
10
