DTS Z8 User Manual

INFRARED MODE
Infrared disabled (default)
Infrared enabled
NOTE:
Internal hardware interface not yet
implemented
External infrared remote sensor needed.
D.T.S. Code :03.LA.016
3. MODE SETTINGS
6. InfraRed mode
7. Emergency setup
INFRARED MODE
Infrared remote control.
By activating INFRARED MODE, it will be
possible to navigate trought the unit
functions by using the D.T.S. infrared
remote control. D.T.S. Code :0514L008.
(Internal hardware interface not yet
implemented)
EMERGENCY SETUP
Mode selection = ON/OFF (default =
OFF)
Macro selection = White COLD,
NATURAL, WARM, FULL, DMX.
Macro DMX Program= Save regolation.
Dimmer level = 0-255 (default = 255)
EMERGENCY SETUP
Emergency operating mode.
By setting Emergency mode, it will be
possible to select one of the 5
preprogrammed WHITE cues that will
then ran if DMX signal is missing or not
available (Dimmer level also selectable by
user). Usefull for Emergency EXIT
ilumination on public areas.
MODE
SETTINGS
Z8 LED Controller
14
LED SETUP
LED Setup
HARDWARE TEST
Hardware test OFF (default)
Hardware test ON
Menu
Up-Down
ENTER Up-Down
ENTER
Hardware test\ LED min setup\ LED
max setup\ MR16 full colour\ Output
filter\ output delay\ Led BOOST.
HARDWARE TEST
Complete hardware test
LED MIN SETUP
This menu allow to select the minimum
levels for Red, Green, Blue and Amber
(external DMX controller needed)
LED MAX SETUP
This menu allow to select the maximum
levels for Red, Green, Blue and
Amber(external DMX controller needed)
MR16 FULL COLOUR
Preprogrammed RGB values for MR16
full colour led lamp
OUTPUT FILTER
Output filter OFF
Output fileter ON (default)
OUTPUT DELAY
This menu allow to select the value of
the delay ( in millisecons) for RGBA and
Dimmer channels reaction to DMX or
Program variation.
No output delay = 25 ms delay
Short output delay = 80 ms delay
Long output delay = 250 ms delay
LED BOOST
Led BOOST (350mA)
Led BOOST Min (420 mA),
Led BOOST Max (500 mA)
4. LED SETUP
1. Hardware test
2. Led MIN setup
3. Led MAX setup
4. MR16 full colour
5. Output filter
4. LED SETUP
6. Output delay
7. Led BOOST
LED MIN SETUP
MIN level RED (default = 0)
MIN level GREEN (default = 0)
MIn level BLUE (default = 0)
MIN level AMBER (default = 0)
(external DMX controller needed)
ENTER
LED MAX SETUP
MAX level RED (default = 255)
MAX level GREEN (default = 255)
MAX level BLUE (default = 255)
MAX level AMBER (default = 255)
(External DMX controller needed)
ENTER
MR16 FULL COLOUR
MR16 limit OFF (Default)
MR16 limit ON
ENTER
OUTPUT FILTER
Output filter OFF
Output filter ON (Default)
ENTER
LED BOOST
Led BOOST disabled (350mA) Default
Led BOOST MIN (420 mA)
Led BOOST MAX (500 mA)
ENTER
OUTPUT DELAY
No output delay
Short delay (default)
Long delay
ENTER
