DTS Z8 - DMX Channel 4: Green Color Control; DMX Channel 5: Blue Color Control; DMX Channel 6: Amber Color Control; DMX Channel 7: White Color Temperature

Z8 LED Controller
DMX CHANNEL
4
Parameter: GREEN
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-255 Proportional colour
DMX CHANNEL
5
Parameter: BLUE
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-255 Proportional colour
IF CHANNEL 10 (FUNCTIONS) = CUSTOM WHITE CREATE (Dmx range value 80 - 160)
Custom White Create (RGB levels selectable by DMX)
White CTC (Channel 8 CTC enabled
43 color temp. Correction Macros: 2000°K-7200°K)
DMX CHANNEL
7
Parameter: WHITE (Pre-programmed White at diff. color temperature)
Move
DMX range Mid point
Mode Option Function
Value DMX value
range
(degrees)
0-55 23
No Function
56-105
80
Full (Red-Green-Blue at Full)
106-155
130
White DTS
IF CHANNEL 10 (FUNCTIONS) = CUSTOM WHITE RECALL (Dmx range value 0 - 79)
Custom White Recall
156-205
180
White CTC (Channel 8 CTC enabled
43 color temp. Correction Macros: 2000°K-7200°K)
225
206-255
156-205
206-255
180
225
DMX CHANNEL
6
Parameter: AMBER
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-255 Proportional colour
22
