DTS Z8 - DMX Protocol: Z1 Type 8-Bit (10 Channels); DMX Channel 8: CTC Color Temperature; DMX Channel 9: Colour Macros Selection; DMX Channel 10: Custom White Functions

Z8 LED Controller
DMX CHANNEL
9
Parameter: COLOUR MACROS
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-14
15-29
30-44
45-59
60-74
75-89
90-104
105-119
120-134
135-149
150-164
165-179
180-194
195-209
210-225
226-239
No Function
Macro 1
Macro 2
Macro 3
Macro
Macro
Macro
Macro
Macro
Macro
Macro
Macro
Macro
Macro 4
Macro 5
Macro 6
Macro 7
Macro 8
Macro 9
Macro 10
Macro 11
Macro 12
Macro
Macro
Macro
Macro 13
Macro 14
Macro 15
240-255
Macro 16
DMX CHANNEL 10
Parameter: FUNCTIONS (Recall,Create and Store the Custom white)
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-79
80-160
161-255
Custom White Recall (Enable CH 7 for Custom white Recall)
Custom White Create (Enable CH 7 for Custom white Creation)
Custom White Store (Store the Custom White created )
DMX CHANNEL
8
Parameter: CTC (Color temperature correction)
Move
DMX range Mid point
Mode Option Function
Value DMX value
range
(degrees)
0-255
IF CHANNEL 7 (White) = WHITE CTC (Dmx range value 206 - 255)
43 color temp. Correction Macros: 0 = 2000°K / 128 = 5500°K / 255 = 7200°K
IF CHANNEL 7 (White) = NO FUNCTION (Dmx range value 0 - 43)
0-255
Smooth RGB linear Hue correction
23
