DMX PROTOCOL
Z8 LED Controller
21
Z8 RGBA “Z1 TYPE - 8 BIT” MAP (10 DMX CHANNELS)
10 CHANNELS MODE
1 SHUTTER
2 DIMMER
3 RED
4 GREEN
5 BLUE
6 AMBER
7 WHITE (Pre-programmed whites at different colour temperatures)
8 CTC
9 COLOURS MACRO
10 FUNCTIONS
DMX CHANNEL
1
Parameter: SHUTTER
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-9 5 Black-out
10-19 14
20-29 24
30-119 Strobe at variable speed from slow to fast (3400ms-20ms)
120-149
192
218
Pulse open at variable speed from slow to fast (43s-100ms)
240
150-179
180-204
205-229
230-255
Open
Black-out
Pulse close at variable speed from slow to fast (43s-100ms)
Random Strobe (Master and RGBA active)
Random Strobe (Full)
Open
DMX CHANNEL
2
Parameter: DIMMER
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-255 Proportional dimmer
DMX CHANNEL
3
Parameter: RED
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-255 Proportional colour
