If it is not possible to start the procedure when the
START is confirmed, after a few seconds the
instrument panel will automatically highlight the
option EXIT.
If an error or malfunction occurs during the calibration
procedure, FAILED message in red will come on at
the top of the display, and after a few seconds it will
be automatically replaced with the main screen.
The rider can abort the procedure both during the
READY stage and during the IN PROGRESS stage, by
pressing button (1) for 2 seconds. ABORTED
message in red will come on at the top of the display,
and after a few seconds it will be automatically
replaced with the main screen.
The values shown in the pictures as required speed
range and gear are just an example and shall not be
considered as binding or corresponding to the ones
actually set for the vehicle.
2
KEEP SPEED
AND GEAR 2
48 - 52 km/h
45
km/h
FAILED
Fig. 119
2
KEEP SPEED
AND GEAR 2
48 - 52 km/h
45
km/h
ABORTED
Fig. 120
177
