Ducati MONSTER 821 - Page 287

Fuse box (A) key
Pos El. item Rat.
1 Optional key 7.5 A
2 Alarm 5 A
3 Stop 5 A
4 Diagnostics 3 A
5 Spare 7.5 A
6 Spare 25 A
7 Spare 30 A
Fuse box (B) key
Pos El. item Rat.
1 Lights 5 A
2 Instrument panel 10 A
3 Key 1 10 A
4 Key 2 15 A
5 Relay 20 A
6 Control unit 5 A
7 BBS 10 A
8 Spare 10 A
9 Spare 20 A
10 Spare 15 A
