Ducati Scrambler Owner's Manual

DEFAULT setting
This function allows setting the DEFAULT units of
measurement according to the vehicle version.
To enter this function gain access to the SETTING
MENU, and keys (1) and (2) to select the UNITS
indication, then press button (4). Press button (1) or
(2) to make the "UNIT:DF" box start flashing and then
press button (4) for 3 seconds.
After 3 seconds, the instrument panel shows "WAIT"
for 2 seconds; then the "DF-OK" message indicates
that the units of measurement have been restored.
4
4
Fig 56
102

Ducati Scrambler Specifications

General

Power	73 hp (54 kW) @ 8, 250 rpm
Transmission	6-speed
Frame	Tubular steel trellis frame
Torque	49 lb-ft (67 Nm) @ 5, 750 rpm
Front Suspension	USD Kayaba 41 mm fork
Rear Suspension	Kayaba rear shock, preload adjustable
Rear Brake	245 mm disc, single-piston caliper
Fuel Tank Capacity	13.5 l (3.6 US gal)
Front Brake	330mm disc, radial 4-piston caliper, ABS
