Ducati Scrambler Owner's Manual

Parameter setting/displaying
Upon key-on, the instrument panel:
- turns on the display backlighting;
- activates the rev counter which increases from 0
to 12000 and then goes back to 0;
- activates the vehicle speed digits and shows a
counting from 0 to 300 and then back to 0;
- turns on the warning lights in a sequence,
starting from the right to the left.
At the end of the check routine, the instrument panel
displays the main screen ("standard screen") showing
the available functions and turns on the warning
lights, if necessary.
During this check stage, if the vehicle speed exceeds
12 mph (20 km/h) (actual speed), the instrument
panel will stop:
- the display check routine and display the
standard screen containing updated information;
- the warning light check routine and leave on only
the warning lights that are actually active at the
moment.
Fig 17
45

Ducati Scrambler Specifications

General

Power	73 hp (54 kW) @ 8, 250 rpm
Transmission	6-speed
Frame	Tubular steel trellis frame
Torque	49 lb-ft (67 Nm) @ 5, 750 rpm
Front Suspension	USD Kayaba 41 mm fork
Rear Suspension	Kayaba rear shock, preload adjustable
Rear Brake	245 mm disc, single-piston caliper
Fuel Tank Capacity	13.5 l (3.6 US gal)
Front Brake	330mm disc, radial 4-piston caliper, ABS
