Ducati Scrambler Owner's Manual

Fuel tank plug
Opening
Insert the key into the lock.
Turn the key clockwise 1/4 turn to unlock.
Loosen plug (1).
Closing
Screw the cap (1) with the key inserted and press it
into its seat.
Turn the key counter clockwise to the original position
and remove it.
Note
The plug can only be closed with the key in.
Attention
Always make sure you have properly refitted
and closed the plug after refueling.
Fig 80
1
Fig 81
128

Ducati Scrambler Specifications

General

Power	73 hp (54 kW) @ 8, 250 rpm
Transmission	6-speed
Frame	Tubular steel trellis frame
Torque	49 lb-ft (67 Nm) @ 5, 750 rpm
Front Suspension	USD Kayaba 41 mm fork
Rear Suspension	Kayaba rear shock, preload adjustable
Rear Brake	245 mm disc, single-piston caliper
Fuel Tank Capacity	13.5 l (3.6 US gal)
Front Brake	330mm disc, radial 4-piston caliper, ABS
