Ducati Scrambler Owner's Manual

Seat lock
Opening
Insert the key (1) in the lock, turn clockwise while
pressing down at the latch to help release the pin.
Remove the seat (2) pulling it backwards until sliding
it out of the front retainers.
Closing
Make sure that all elements are correctly positioned
and fastened to the compartment under the seat.
Slide the front end (A) of the seat bottom underneath
the retainer (B) of the frame support.
Press on seat (2) rear end until locking latch snaps.
Make sure the seat is safely secured to the frame and
remove the key (1) from the lock.
2
1
Fig 82
2
B
A
Fig 83
129

Ducati Scrambler Specifications

General

Power	73 hp (54 kW) @ 8, 250 rpm
Transmission	6-speed
Frame	Tubular steel trellis frame
Torque	49 lb-ft (67 Nm) @ 5, 750 rpm
Front Suspension	USD Kayaba 41 mm fork
Rear Suspension	Kayaba rear shock, preload adjustable
Rear Brake	245 mm disc, single-piston caliper
Fuel Tank Capacity	13.5 l (3.6 US gal)
Front Brake	330mm disc, radial 4-piston caliper, ABS
