Ducati Scrambler Owner's Manual

California evaporation emission system
This system consists of:
1) Warn air inlet;
2) Canister;
3) Dell’Orto jet;
4) Fuel tank;
5) Breather pipe;
6) Intake manifolds.
Attention
In the event of fuel system malfunction, contact
Ducati’s authorized Service Centres.
1 5
3
6
2
4
CANISTER
Fig 14
34

Ducati Scrambler Specifications

General

Power	73 hp (54 kW) @ 8, 250 rpm
Transmission	6-speed
Frame	Tubular steel trellis frame
Torque	49 lb-ft (67 Nm) @ 5, 750 rpm
Front Suspension	USD Kayaba 41 mm fork
Rear Suspension	Kayaba rear shock, preload adjustable
Rear Brake	245 mm disc, single-piston caliper
Fuel Tank Capacity	13.5 l (3.6 US gal)
Front Brake	330mm disc, radial 4-piston caliper, ABS
