Ducati Scrambler Owner's Manual

Starting the engine
Attention
Before starting the engine, become familiar
with the controls you will need to use when riding.
Attention
Never start or run the engine indoors. Exhaust
gases are poisonous and may lead to loss of
consciousness or even death within a short time.
Move the ignition key to position (1, Fig 92). Make
sure both the green light N and the red light
on
the instrument panel come on.
Important
The oil pressure light should go out a few
seconds after the engine has started.
1
Fig 92
Fig 93
139

Ducati Scrambler Specifications

General

Power	73 hp (54 kW) @ 8, 250 rpm
Transmission	6-speed
Frame	Tubular steel trellis frame
Torque	49 lb-ft (67 Nm) @ 5, 750 rpm
Front Suspension	USD Kayaba 41 mm fork
Rear Suspension	Kayaba rear shock, preload adjustable
Rear Brake	245 mm disc, single-piston caliper
Fuel Tank Capacity	13.5 l (3.6 US gal)
Front Brake	330mm disc, radial 4-piston caliper, ABS
