Ducati Scrambler Owner's Manual

Engine
Twin cylinder, four-stroke, 90° "L" type, longitudinal.
Bore:
3.46 in (88 mm).
Stroke:
2.6 in (66 mm).
Total displacement, cu. cm:
803
Compression ratio: 11±0.5:1
Max. power at crankshaft (95/1/EC):
55 kW - 74 CV at 8.250 rpm
Max. torque at crankshaft (95/1/EC):
68 Nm - 6.9 Kgm at 5.750 rpm.
Maximum rpm:
9,200.
Important
Do not exceed the specified rpm limits in any
running conditions.
184

Ducati Scrambler Specifications

General

Power	73 hp (54 kW) @ 8, 250 rpm
Transmission	6-speed
Frame	Tubular steel trellis frame
Torque	49 lb-ft (67 Nm) @ 5, 750 rpm
Front Suspension	USD Kayaba 41 mm fork
Rear Suspension	Kayaba rear shock, preload adjustable
Rear Brake	245 mm disc, single-piston caliper
Fuel Tank Capacity	13.5 l (3.6 US gal)
Front Brake	330mm disc, radial 4-piston caliper, ABS
