Function push-buttons
1) CONTROL SWITCH UP " "
Button used to display and set instrument panel
parameters with the position " ".
2) CONTROL SWITCH DOWN " "
Button used to display and set instrument panel
parameters with the position " ".
3) HIGH-BEAM FLASH BUTTON FLASH
This button is the high-beam flasher.
4) TURN INDICATORS CANCEL BUTTON
The turn indicators cancel button may also be used
for the CONFIRM MENU function, for selecting the
riding style. Press this button for 3 seconds to the left
side to activate the "Hazard" lights.
4
3
2
1
Fig 16
44

Ducati Scrambler Specifications

General

Power	73 hp (54 kW) @ 8, 250 rpm
Transmission	6-speed
Frame	Tubular steel trellis frame
Torque	49 lb-ft (67 Nm) @ 5, 750 rpm
Front Suspension	USD Kayaba 41 mm fork
Rear Suspension	Kayaba rear shock, preload adjustable
Rear Brake	245 mm disc, single-piston caliper
Fuel Tank Capacity	13.5 l (3.6 US gal)
Front Brake	330mm disc, radial 4-piston caliper, ABS
