Ducati Scrambler Owner's Manual

Electric system
Basic electric items are:
Headlight:
low/high beam: H4 bulb (12V – 60/55W);
parking light: no. 1 LED (3.1W — 13.5V)
Electrical controls on handlebars.
Turn indicators:
front: 12V RY10W bulb;
rear: 12 VRY10W bulb.
Horn.
Stop light switches.
Battery, 12V-10 Ah, dry.
GENERATOR 14V-490W.
ELECTRONIC RECTIFIER, protected by a 30A fuse
located next to fuse box (C,Fig 130).
Starter motor: 12V-0.7 kW.
Tail light:
parking light: 2 LEDs (3.24W -12V);
stop light: 6 LEDs (7.9W-12V).
Number plate light:
lamp: 3 LEDs (0.67W-13.5V).
Note
For bulb replacement instructions, please read
"Replacing the high and low beam bulbs".
Fuses
There are seven fuses that protect the electric
components located inside the fuse box, and one on
the electric solenoid starter. The fuse box includes
two spare fuses.
Refer to the table below to identify the circuits
protected by the various fuses and their ratings.
191

Ducati Scrambler Specifications

General

Power	73 hp (54 kW) @ 8, 250 rpm
Transmission	6-speed
Frame	Tubular steel trellis frame
Torque	49 lb-ft (67 Nm) @ 5, 750 rpm
Front Suspension	USD Kayaba 41 mm fork
Rear Suspension	Kayaba rear shock, preload adjustable
Rear Brake	245 mm disc, single-piston caliper
Fuel Tank Capacity	13.5 l (3.6 US gal)
Front Brake	330mm disc, radial 4-piston caliper, ABS
