Ducati Scrambler Owner's Manual

Replacing the headlight bulbs
Important
Have the bulbs replaced at a Ducati Dealer or
Authorized Service Center.
Attention
The headlight might fog up if the vehicle is used
under the rain or after washing. Switch headlight on
for a short time to dry up any condensate.
Before replacing a blown bulb, make sure that the
replacement bulb has the same voltage and power as
that specified in the paragraph "Electrical System" on
page 191. Always check that the bulb functions
before reassembling removed parts.
Loosen screws (1) and collect headlight support U-
bolts (2).
1
1
2
2
Fig 113
160

Ducati Scrambler Specifications

General

Power	73 hp (54 kW) @ 8, 250 rpm
Transmission	6-speed
Frame	Tubular steel trellis frame
Torque	49 lb-ft (67 Nm) @ 5, 750 rpm
Front Suspension	USD Kayaba 41 mm fork
Rear Suspension	Kayaba rear shock, preload adjustable
Rear Brake	245 mm disc, single-piston caliper
Fuel Tank Capacity	13.5 l (3.6 US gal)
Front Brake	330mm disc, radial 4-piston caliper, ABS
