Ducati Scrambler Owner's Manual

Adjusting the position of the gearchange
pedal and rear brake pedal
The position of the gearchange and rear brake pedals
in relation to the footrests can be adjusted to suit the
requirements of the rider.
Adjust the pedals as follows:
Gear change pedal
hold the linkage (1) and slacken the lock nuts (2) and
(3).
Note
Nut (2) features a left-hand threading.
Fit an open-end wrench to hexagonal element of
linkage (1) and rotate until setting pedal in the desired
position. Tighten both check nuts onto linkage.
2
3
1
Fig 77
125

Ducati Scrambler Specifications

General

Power	73 hp (54 kW) @ 8, 250 rpm
Transmission	6-speed
Frame	Tubular steel trellis frame
Torque	49 lb-ft (67 Nm) @ 5, 750 rpm
Front Suspension	USD Kayaba 41 mm fork
Rear Suspension	Kayaba rear shock, preload adjustable
Rear Brake	245 mm disc, single-piston caliper
Fuel Tank Capacity	13.5 l (3.6 US gal)
Front Brake	330mm disc, radial 4-piston caliper, ABS
