Ducati Scrambler Owner's Manual

Rear brake pedal
Loosen counter nut (4).
Turn pedal stroke adjusting screw (5) until pedal is in
the desired position. Tighten the counter nut (4).
Operate the pedal by hand to check that there is
about 0.06-0.08 in (1.5-2 mm) of free play before the
brake bites. If not, adjust the length of the master
cylinder pushrod as follows.
Loosen lock nut (6) on master cylinder rod.
Tighten rod (7) on fork (8) to increase clearance or
loosen it to decrease it.
Tighten lock nut (6) and check again clearance.
5
8
7
6
4
Fig 78
126

Ducati Scrambler Specifications

General

Power	73 hp (54 kW) @ 8, 250 rpm
Transmission	6-speed
Frame	Tubular steel trellis frame
Torque	49 lb-ft (67 Nm) @ 5, 750 rpm
Front Suspension	USD Kayaba 41 mm fork
Rear Suspension	Kayaba rear shock, preload adjustable
Rear Brake	245 mm disc, single-piston caliper
Fuel Tank Capacity	13.5 l (3.6 US gal)
Front Brake	330mm disc, radial 4-piston caliper, ABS
