Ducati Scrambler Owner's Manual

Left-hand switch
1) Dip switch, light dip switch, two positions:
position = low beam on (A);
position = high beam on (B);
Button = high-beam flasher (FLASH) and
instrument panel control (C).
2) Switch = 3-position turn indicator control:
central position = off;
position
= left turn;
position = right turn.
To disable the turn indicator, press the control
once it returns to center position.
3) Button
= warning horn.
4) Instrument panel control switch, position " ".
5) Instrument panel control switch, position " ".
1
B
C
A
Fig 64
253
4
1
Fig 65
116

Ducati Scrambler Specifications

General

Power	73 hp (54 kW) @ 8, 250 rpm
Transmission	6-speed
Frame	Tubular steel trellis frame
Torque	49 lb-ft (67 Nm) @ 5, 750 rpm
Front Suspension	USD Kayaba 41 mm fork
Rear Suspension	Kayaba rear shock, preload adjustable
Rear Brake	245 mm disc, single-piston caliper
Fuel Tank Capacity	13.5 l (3.6 US gal)
Front Brake	330mm disc, radial 4-piston caliper, ABS
