Ducati Scrambler Owner's Manual

Adjuster (2), located on the lever, allows a maximum
value (Q) of 0.43 in (11 mm), whereas the (factory)
standard setting is 0.20 in (5 mm). If working on such
adjuster proves insufficient, work on the secondary
adjuster (3).
Attention
In case of a slipping clutch due to clutch wear,
adjuster (2) on the lever must NEVER be loosened,
but screwed, as described above.
If the clutch is still slipping, go to a Dealer or a Ducati
Authorized Service Center.
2
1
Q
Fig 68
3
Fig 69
119

Ducati Scrambler Specifications

General

Power	73 hp (54 kW) @ 8, 250 rpm
Transmission	6-speed
Frame	Tubular steel trellis frame
Torque	49 lb-ft (67 Nm) @ 5, 750 rpm
Front Suspension	USD Kayaba 41 mm fork
Rear Suspension	Kayaba rear shock, preload adjustable
Rear Brake	245 mm disc, single-piston caliper
Fuel Tank Capacity	13.5 l (3.6 US gal)
Front Brake	330mm disc, radial 4-piston caliper, ABS
