Ducati Scrambler Owner's Manual

Aligning the headlight
The vertical alignment of the headlight can be
manually set by turning screw (1).
Important
Headlight beam adjuster screw has no limit
stop.
Attention
The headlight might fog up if the vehicle is used
under the rain or after washing. Switch headlight on
for a short time to dry up any condensate.
1
Fig 121
165

Ducati Scrambler Specifications

General

Power	73 hp (54 kW) @ 8, 250 rpm
Transmission	6-speed
Frame	Tubular steel trellis frame
Torque	49 lb-ft (67 Nm) @ 5, 750 rpm
Front Suspension	USD Kayaba 41 mm fork
Rear Suspension	Kayaba rear shock, preload adjustable
Rear Brake	245 mm disc, single-piston caliper
Fuel Tank Capacity	13.5 l (3.6 US gal)
Front Brake	330mm disc, radial 4-piston caliper, ABS
