51) RH heated handgrip
52) Front left turn indicator
53) Headlight
54) Front right turn indicator
55) Horn
Wire color coding
B Blue
W White
V Violet
Bk Black
Y Yellow
R Red
Lb Light blue
Gr Gray
G Green
Bn Brown
O Orange
P Pink
Note
The electric system wiring diagram is at the end
of this manual.
195
