Entering the PIN CODE
To activate the PIN CODE function and enter your
own PIN CODE you must open the Setting MENU.
Select PIN CODE option, by pressing button (1) or (2).
Once function is highlighted, press CONFIRM MENU
button (4).
Note
If upon accessing this function, the "O : " (Old)
indication is displayed together with four flashing
dashes "- - - -", a PIN code is already stored and the
Function is already active.
When accessing the function, the display will show
"N:" (new) followed by four flashing dashes "- - - -".
To go back to the previous screen without activating
any PIN CODE, press button (2); as soon as the "EXIT"
box starts flashing, press button (4) again.
Entering the code:
1) Press button (4), one digit starts flashing
indicating "0";
2) Each time you press the button (2) the displayed
number increases by one (+ 1) up to "9" and then
starts back from "0";
3) Each time you press the button (1) the displayed
number decreases by one (- 1) up to "1" and then
starts back from "0";
4) To confirm the number, press the button (4);
Repeat the procedures until you confirm all the four
digits of the PIN CODE.
88

Table of Contents

Other manuals for Ducati Scrambler

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ducati Scrambler and is the answer not in the manual?

Ducati Scrambler Specifications

General IconGeneral
Power73 hp (54 kW) @ 8, 250 rpm
Transmission6-speed
FrameTubular steel trellis frame
Torque49 lb-ft (67 Nm) @ 5, 750 rpm
Front SuspensionUSD Kayaba 41 mm fork
Rear SuspensionKayaba rear shock, preload adjustable
Rear Brake245 mm disc, single-piston caliper
Fuel Tank Capacity13.5 l (3.6 US gal)
Front Brake330mm disc, radial 4-piston caliper, ABS
