Manual Programming - DC545 HCEX
Also consider that the unprintable margin of a digital press is typically 3 to 5 mm from the edge of the sheet, so the edge
of the image should not be placed more than 205 mm from the reference edge.
To avoid the problem of the image drifting into the unprintable margin (which would result in a white edge inside the
image area), the image should possess a bleed of (typically) 2mm.
With all these factors combined, it is recommended that the right trim position is located between 202 and 204 mm from
the reference edge.
Definition of Programming Terms
202-204mm
typically
Workaround - Should a job be presented that requires a side trim of less than 200 mm, use the right center slitter, OP1,
or OP2 slitter to remove the waste from the side. The waste will exit onto the delivery tray.
5) Skewed Output on Small Pieces
Depending on the job layout it is possible to have skewed output when small pieces are processed. In part, this problem
is due to the design of the rubber feed rollers. Each roller has cutouts that reduce the gripping and drive area for the
paper. In addition, the slitter units add drag as the card contacts the slitter housing and cutter wheels.
Workaround - Analyze the slitter positions and reprogram the job. Switch the center and option slitter units cutting
positions in order to better balance the paper as it travels through the slitters.
Docu Cutter(HCEX) 5_53-69 03.12.8, 3:11 PM59
