34
PC Controller Setting
Main Menu
This menu appears when the PC Controller is launched.
Select the sub menu to set from this main menu screen, for actual settings.
Number
Item Function
1
WIZARD
Create a JOB in Wizard format.
A preview of the JOB being created is displayed. Create the JOB
while checking the input details.
2 DIRECT
Directly input the number value to create a JOB.
Use this to create a JOB rather than “WIZARD” when the
dimensions are already fi nalized.
3 UPLOAD Read the JOB from the DC-616 and save in computer.
4 SETTING This is used to set the default values of the PC Controller.
5 MAINTENANCE
For service person use only. This is used for setting the machine
etc. Password is required to access.
6 SELECT This reads the saved JOBs on the DC-616. Select one from them.
Insert the “Dongle” in the USB port of your computer.
When you create/save a JOB with your computer unconnected to the DC-616, the Dongle is
not necessary.
1
2
3
4
5
24
19
20
21
6
7
8
9
10
11
15
16
17
18
12
13
14
22
23
25
To Next Page
