38
PC Controller Setting
PC Controller Setting
Creating a JOB with Preview Display (WIZARD)
This section describes the procedures to set up a JOB in Wizard format. Following items
should be entered to create a JOB.
JOB No.
Select a JOB No. in which the JOB currently being programmed is saved.
JOB Name
Put a name to the JOB with your keyboard for easy reference.
Paper Size
Enter size of the document.
Standard document size can be selected from “Standard size”, or custom size can be
entered in “Custom size”.
Finished Size
Specify the size of cards after processing the documents.
Cards per Document
Specify how many cards are to be aligned in crosswise and in lengthwise direction.
Trim
Specify the position of the fi rst cut and right margin slit.
Gutter Slits (Distance between fi nished documents (left/right))
When aligning 2 or 3 cards in crosswise direction, it is possible to have a gutter slit between
each card.
Specify the distance between each card.
Gutter Cuts (Distance between fi nished documents (top/bottom))
When aligning 2 or more cards in lengthwise direction, it is possible to have a gutter cut
between each card.
Specify the distance between each card.
Reg. Mark
Select whether to use REG. Mark function or not.
When using this function, enter the position of REG. Mark.
Crease
Specify the position of the crease on the cards.
Up to 20 creases can be set on a document.
Perforation Unit
Perforates parallel to the document feed direction.
Inch>> mm
The values entered in inches are converted to the values in millimeters automatically
.
To Next Page
