PC Controller Setting

REFERENCE

You can ﬁ ne-adjust the setting positions of the JOB.

[Up] : Each click on “Up” decreases the value by

0.1 mm in the vertical direction. (Upward)

[Down]: Each click on “Down” increases the value by

0.1 mm in the vertical direction. (Downward)

[Left] : Each click on “Left” increases the value by

0.1 mm in the horizontal direction. (To the

left)

[Right] : Each click on “Right” decreases the value by

0.1 mm in the horizontal direction. (To the

right)

From here, follow steps 19–21 of “Creating a JOB with Preview Display (WIZARD)”.

(See →P.46)

Reading a JOB from DC-616 ( UPLOAD)

This section describes the procedures to read JOBs (upload) from the DC-616 to your

computer.

Select the [Connect] check box to connect the line.

Click [UPLOAD].

● Uploading all JOBs from the DC-616

1. Click [ALL JOBS] and click [UPLOAD].

With the above operations, JOB No. 1 to 80 are

saved in one ﬁ le.

REFERENCE

2. Click [YES].

Clicking [NO] returns to the previous screen without

uploading.
