PC Controller Setting
PC Controller Setting
5
REFERENCE
● Standard Size
Click [Standard Size] and select from the [Paper Size] box.
Then click [NEXT].
You can set “Custom Size” in the following range.
Width: 210 to 320 mm
Length: 210 to 670 mm
Paper Size
● Custom Size
Select [Custom Size] when using other than the
standard size document.
Enter the value of document width and length, and
click [NEXT].
REG. Mark
Click [REG. Mark enable] to use the REG. Mark reading
function.
Enter the distance from the right edge of the document
to the side mark in the [Side Mark] box, then click
[NEXT].
Enter the distance from the lead edge of the document
to the lead mark in the [Lead Mark] box, then click
[NEXT].
REFERENCE
Side mark: 3.0 to 15.0 mm (From the right edge of the document)
Lead mark: 3.0 to 15.0 mm (From the top edge of the document)
Finished size
Enter the value of the fi nished document width in the
[Width] box, and click [NEXT].
Then enter the value of the fi nished document length in
the [Length] box, and click [NEXT].
Cards per Document
Enter the number of cards in the [Crosswise] box, and
click [NEXT].
Then enter the number of cards in the [Lengthwise]
box, and click [NEXT].
Click [REG. Mark disable] when you do not use the REG. Mark reading function.
Then click [NEXT].
To Next Page
