24
Before Using This Machine
When both REG mark and barcode are printed on one document:
● When
REG Mark Spec
is set to
Standard
:
A REG mark or a barcode located out of the specifi ed printing area cannot be detected
properly.
Take account of the possible variation in the printed position of a REG mark and a barcode
when they are arranged on the document.
● When
REG Mark Spec
is set to
Bold
:
60.0 mm or less
35.0 mm 20.0 mm
20.0 mm
3.0 mm
Barcode
Document
feed
direction
60.0 mm or less
35.0 mm
12.0 mm10.0 mm
20.0 mm
5.0 mm
3.0 mm
Barcode
Document
feed
direction
REG mark
REG mark
3.0 mm
3.0 mm
5.0 mm
3.0 mm
