Before Using This Machine
1
Before Using This Machine
3.0 mm
or more
Make sure that no part of the image to be printed enters the gray-colored area.
Make sure that no other printings than a REG mark or a barcode enters the gray-colored area.
35.0 mm
5.0 mm
20.0 mm
Barcode
Document
feed
direction
20.0 mm
3.0 mm or more
Non-printing
area
Non-printing area
REG mark
1.0 mm or more
1.0 mm
or more
