When both REG.Mark and Barcode are Printed
3mm
5mm or more
60mm or less
0.4mm or more
5mm
or more
20mm
3mm
3mm
20mm35mm
Feed Direction
Barcode
Barcode
Position Range
REG. Mark
Position Range
5mm
REG. Mark
3mm
or more
20mm
20mm35mm
Feed Direction
Non Printing Area
Barcode
5mm
REG. Mark
3mm
or more
3mm
or more
Ifthereisanystainorscratchthatis0.3mmorlessintheslasharea,themarginoferrorinthefinishmay
slightlyincrease.
WhenREG.MARKand/orBARCODEareprintedoutsidethespecifiedarea,DC-645cannotdetectthem
properly.WhenpositioningtheREGmarkandBARCODEonthedocument,takethepossibilityofimage
shiftintoconsideration.
Non-Printing Area
Theprintimageshouldnotinterferethered-coloredarea.
