15. Technical Data
15.1 Identification Plate
The identification plate is on the back page of the operating instructions. This product
conforms to all the appropriate EU guidelines.
15.2 Filling volume
Blue Moon 730 l
Sundeck 493 l
15.3 Whirlpool
Rated voltage 220–240 V - (AC)
Frequency 76xxxx 00 0 PS xx00 50 Hz,
76xxxx 00 0 PS xx06 60 Hz
Max. rated power
• Heater element 3 KW
• Whirl system 3 KW
Protection class I
Protection rating IP X5, protection against sprayed water (from any direction)
Average energy consumption of the pool (pool with insulated lining, covered with
floating film, tub covers / relaxing deck and tarpaulin). The values can vary greatly in
an individual case due to user behaviour and weather and serve only for guidance:
Blue Moon Sundeck
0 °C/32 °F 0.3 kW/h 0.3 kW/h
15°C/59°F 0.2 kW/h 0.2 kW/h
25°C/77°F 0.1 kW/h 0.1 kW/h
15.4 Remote control
Temperature range 0-45 °C/32-113 °F
Protection rating IP X8, protection against continuous submersion
