DURKOPP ADLER 559 - 7 Push Button; 8 Setting the Cloth Stops

7. Push button
By means of the push button it is possible to c ontrol the clamps and to
start the sewing operation. According to the adjustment in the service
menu (see service instructions) the function is different.
1. Adjustment
–
Key 1: The clamps are opened or closed respectively.
–
Key 2: The sewing operation starts when the clamps are closed.
2. Adjustment
–
Key 1: The clamps are opened or closed respectively.
–
Key 2: If the clamps are not lowered, they will be lowered now. The
sewing operation starts.
8. Setting the cloth stops
Caution: Danger of injury !
Adjust the cloth stops only when the automatic buttonholer is
switched off!
–
Place the sewing material until it touches the cloth stops 2 on both
sides (right and left).
–
Loosen the screws 1 on the right and left.
–
Adjust the sewing position by moving the cloth stops 2.
–
Tighten the screws 1 again.
18
1
1
2
