Replacing the knife
Loosen screw 1 and remove the fabric holder 4.
Take out the old knife 2.
Stick the new knife 3 in the groove and snap it off in the arrow
direction.
Tighten the screw 1.
Fix the fabric holder using the screw 4.
Hint!
The knife may not exceed
the fabric holder.
11. Information messages
11.1 Needle not in basic position
If the needle is not in its basic position at the sewing start, the
information code in the margin appears.
Correction
Turn the handwheel until the info disappears. (See chapter 8.3)
11.2 Pressure monitor
The pressure monitor supervises the pressure of the air inlet. If no
compressed air is available or the pressure is too low, the information
code in the margin appears in the display.
Correction
Switch the sewing automat off.
Provide sufficient compressed air.
Switch the sewing automat on.
11.3 Thread breakage
Should the thread breaks during the sewing operation, the information
code in the margin appears in the display.
Correction
Press the button at the head cover to get into the “threading mode”.
Thread in the thread new.
30
3
1
1
2
4
