DURKOPP ADLER 559 Operating Instructions

Menu item Description
143 Eyelet inclination: the buttonhole eye can be slightly inclined to the left or to the right.
150 Throw w idth: the mechanically r egulated throw width (stitch width) can
be enlarged/reduced of 0.5mm.
160 Cutting adjustments
161 Cutting mode: depending on the s ewing equipment, the buttonhole c ut can be
set either after sewing (1), before (2), or not at all.
0 = no cutting
1 = cutting after sewing (CA)
2 = cutting before sewing (CB)
162 Cutting area: the internal distance between the two lips of the buttonhole
is meant by cutting area.
163 Cutting correction in x-direction: the knife position can be displaced to the right/left
within the buttonhole.
164 Cutting correction in y-direction: the knife position can be displaced to the rear/front
within the buttonhole.
165 Correction of cutting pressure: automatic adjustment (4 steps) of the cutting force
of the buttonhole knife depending on the buttonhole length.
-buttonhole length (eyelets) up to 14 mm 2 steps
-buttonhole length from 15 mm to 30 mm 3 steps
-buttonhole length from 31 mm 4 steps
The preset cutting force can be increased/decreased in the above menu item,
depending on the buttonhole length.
170 Taper tack adjustments
171 Taper tack length: the taper tack length can be set from 2 mm to 36 mm, depending
on the equipment and the buttonhole length.
172 Throw w idth in the taper tack: the mechanically regulated throw width (stitch width)
can be enlarged/reduced.
Attention! The enlargement depends on the setting of the throw width in menu item 150.
173 Overlapping in the taper tack: overlapping of the buttonhole seams.
174 Height of the tack slant: the taper length in the tack is adjustable.
180 Cross tack adjustments
181 Cross tack length: the overall length of the cross tack.
182 Stitch length in the cross tack: distance from stitch to stitch w ithin the cross
tack (from 0,5 mm to 2 mm).
183 Throw w idth in the cross tack: the mechanically regulated throw width
(stitch width) can be enlarged/reduced.
Attention! The enlargement depends on the setting of the throw width in menu item 150.
184 x-position of the cross tack: the whole cross tack can be s hifted to the right/left.
185 Seam extension in the cross tack: the overlapping of the buttonhole seams
with the cross tack is meant by seam extension in the cross tack.
1
25
