12.3 Change Oil
ATTENTION !
The oil has to be changed after the first 500 operating hours.
Thereafter it has to be changed every tw o years, independent
of the number of operating hours.
Oil the special s ewing machine exclusively with lubricating oil DA-10 or
an equivalent oil with the following specification:
- Viscosity at 40° C: 10mm
2
/s
- Ignition point: 150 ° C
DA-10 can be bought at the sales points of the
DÜRKOPP ADLER AG under the following parts numbers:
250-ml-Container: 9047 000011
1-Litre-Container: 9047 000012
2-Litre-Container: 9047 000013
5-Litre-Container: 9047 000014
Caution: Danger of injury !
Switch off main switch.
Change oil only w hen sewing machine is switched off.
Oil can cause skin eruption.
Avoid a longer contact with the skin.
Wash yourself thoroughly after a contact.
–
Screw off cover of the oil pan.
–
Unscrew locking screw 3 and drain off used oil. Deliver used oil to
an authorized collecting station.
–
Clean oil pan and ventilation tube 4.
–
Clean fluid reservoir 1 and sintered metal filter 2.
–
Screw in locking screw 3 with a new sealing ring 5.
–
Screw on cover of the oil pan w ith a new gasket.
–
Fill up fresh oil via charging funnel 6 (see operating instructions).
48
12 4 635
