20. Maintenance
Caution Risk of Injury !
Turnthemainswitchoff.
The maintenance of the special sewing machine may only be
conducted with the machine turned off.
The maintenance tasks to be conducted daily and weekly by the
operating personnel of the s pecial sewing machine (cleaning and oiling)
are described in Part 1: Operating Instructions. They are included in the
following table only for the sake of completeness.
Work to be done Operating hours
8 40 160 500
Machine head
Remove lint accumulations, s ewing dust, thread rests and
cutting residue from the area of the hook, thread trimmer,
needle plate, feed dog and sewing head .................... X
Checktheoillevelintheoilpan ......................... X
Checktheoilfeedattheviewingglass..................... X
Check hook lubrication .............................. X
Checkthefunctionofthesafetyclutch..................... X
Checkthetimingbelts............................... X
Drive unit
Check the condition and tension of the V-belt ................. X
Pneumatic system
Check the water level in the pressure regulator ................ X
Clean the filter insert in the maintenance unit ................. X
Checkthesystemforleaks............................ X
ATTENTION !
The oil should be changed after the first 500 hours of operation.
The oil is to be changed every 2 years, independent of the number of
hours of operation.
95
GB
