DURKOPP ADLER 867 Instruction Manual

4.1 Optionnal equipment for machines with direct drive
For the 867 with direct drive, the following optional equipments are
available:
Order No. Optional equipment Subclasses
867-190020-M 867-190142-M
0867 590014 Electro-pneumatic needle cooler from the top x
(NK 20-1)
0867 590024 Electro-pneumatic needle cooler from the bottom x
(NK 20-2)
0867 590054 Electro-pneumatic needle cooler from the bottom
(NK 20-5)
0867 590104 Thread monitor for hook thread large hook,
single needle (RFW 20-1)
0867 590124 Thread monitor for hook thread large hook,
double needle (RFW 20-2)
0867 590114 Thread monitor for hook thread oversized x
hook (XXL), single needle (RFW 20-3)
0867 590134 Thread monitor for hook thread oversized
hook (XXL), double needle (RFW 20-4)
0867 590164 Thread monitor for hook thread short t hread cut.,
oversized hook (XXL), single n eedle (RFW 20-7)
0867 590174 Thread monitor for hook thread short t hread cut.,
oversized hook (XXL), double needle (RFW 20-8)
0867 590184 Thread monitor for hook thread short t hread cut.,
large hook, single needle (RFW 20-9)
9780 000108 WE-8 Maintenance unit for pneumatic x x
optional equimpments
0867 490100 Operating panel L-bracket for direct drive x o
9822 510003 Halogen sewing lamp x x
9880 867100 Sewing lamp add-on kit x x
0798 500088 Sewing lamp transformer x x
9880 867103 Sewing lamp LED x x
9880 867102 Integrated LED lamp x x
9850 001089 Power supply cpl. foe integrated sew. lamp / LED x x
0797 003031 Pneumatic connection package x x
0367 595124 Mechanical sewing foot lifting x
0867 590354 Pneumatic sewing foot lifting(FLP 20-1) x
x = Optional equipment
o = Standard equipment
18
Keystone Sewing Machine Company, Inc.

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
