DURKOPP ADLER 867 Instruction Manual

6.1.3 Threading the needle thread on subclass -190146
–
Thread in the thread through the threading
guide 1.
–
Thread in the thread around the pre-tensioner
wheel 2.
–
Conduct the thread through the thread clamp 3.
–
Thread in the thread through the threading
guide 4 on the thread retainer and the eyelets 8
on the tension plate.
–
Conduct the thread through the main tensioner
wheels 7 and 6.
–
Conduct the thread from above through the
tension discs 5.
36
1
2
3
4
8
7
6
5
Keystone Sewing Machine Company, Inc.

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
