DURKOPP ADLER 867 Instruction Manual

6.15.1 Adjusting the stitch length on automotive machines
On automotive machines, the setting wheels 3 and 4 for the stitch
length are secured against altering through the user.
Adjusting the stitch length
Caution: danger of injury !
Tur n off t he main switch.
The stitch length may only be adjusted with the machine switched off.
–
Loosen the clamping screws 5.
–
Introduce a 3 mm Allen key via the holes 6 to reach the clamping
screws 5.
–
Adjust the stitch length according to the description given under
chapter 6.15.
–
Fasten the clamping screws 5 again.
57
GB
43
5
Keystone Sewing Machine Company, Inc.

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
